Outstanding Design
High speed printing engine
High speed printing engine
Uptime increasing with less staff interruption
Wide-range, optional encoding modules
Intuitive user interface
Compact and pghtweight body
Low noise in service
Wide-range & Field Upgradable Encoding Options
Contact smart IC chip encoding module
Contactless (RFID) encoding module
Magnetic stripe card encoding module
Other Flexibipties
Fppper module
Ethernet connection module
High capacity input hopper (400 cards loader)
| Print Technology: | Dye Sublimation (Direct-to-card) |
| Print Capability: |
Edge-to-edge printing One-sided or dual-sided printing Full color (YMCKO) and monochrome printing |
| Print Resolution | 300dpi |
| Display | LCM (Liquid Crystal Monitor) |
| Memory | 32MB |
| Print Speed |
Full color printing (YMCKO) up to 180 cards per hour Monochrome black printing up to 1400 cards per hour |
| Card Format | Windows 2000/XP/2003; Mac driver |
| Input Capacity: | 100 cards (0.76mm / 30mil) |
| Output Capacity: | 50 cards (0.76mm / 30mil) |
| Supported OS | Windows 2000,XP,Visa,Windows 7 (32/64-bit) |
| Bundled Software | CardDesirre CS |
| Printer Dimension | 197.8mm(W) x 354mm(L) x204(H)mm |
| Printer Net Weight | 4.9kg / 10.8Ibs (print media excluded) |
| Operating Condition | 15~32℃(59~ 89.6&°F),20~75% RH non-condensing |
| Print Media |
Full panel YMCKO 400 roll (Ribbon only) ,16 rolls in a carton 1/2 panel YMCKO 560 roll (Ribbon only) ,16 rolls in a carton Monochrome Resin Black 1000 roll (Ribbon only) ,16 rolls in a carton |
| Operating Encoding Modules |
Contact smart IC chip encoding module Contactless (RFID) encoding module (ISO 14443A & B, ISO 15693) Magnetic stripe card encoding module (ISO7811 Hi-co / Low-co) |
| Other Options & Accessories: |
Flipper module High capacity input hopper (400 cards loader) Ethernet TCP-IP connection module - Availability to be updated Cleaning roller (Dust arrester excluded) - Availability to be updated |
