Contact IC card reader&writer

TT6

Applications

The interface of TT6 contact IC card reader can be USB or RS232. The USB is plug- and-play. TT6 has drop-in card holder. It’s compact and ergonomics. TT6 is designed with single hand pulling in/out the card. It’s easy to use and ideal for the counter business with busy card transactions. TT6 can have as much as 4 card holders. The main card holder is for normal using. The side card holder you can insert the administrator card for verifying and managing. This is different from most readers in the market that must use built-in SAM card for administrating. Meanwhile, TT6 can add two more built-in SAM card holders for compatible and multiple verifying purposes.

TT6 contact IC card reader is typical designed with integration of USB flash drive and password protection. The USB flash drive can store software and data. It can work itself. TT6 allows you to set the passport protection of the card reader in order to make the system control more secure.

TT6 contact IC card reader is an essential device of IC card system integration. It upgrades the system security and operation convenience. TT6 can use successfully in the smart card managing system of industry, commerce, telecom, post, tax, bank, insurance and medical for tolling, charging, prepaid and inquiry etc.

Specification

Product Name TT6 card reader
Weight 350g
Temperature -20 to +60ºC
Card reader head lifetime 200,000 times
Supporting card size Maximum two ISO7816 standard cards, and two GSM 11.11 SIM cards (the SAM card holder is optional)
Flash drive 16M, 32M, 64M or customized
Password protection Optional
Supply current to the card 0-70mA
Interface to PC RS232 Low Speed USB(USB 1.1), plug-and-play
Communication protocol CPU card T=0、T=1 Most of the memory cards, logic encryption cards in the market Communication speed of the same card can up to 115,200 bps
Standards ISO 7816-3、PC/SC、GSM11.11、FCC、 CE
Communication speed T=0:9600-38400bps T=1:9600-115200bps
Color As product photo shown, can be customized
USB Cable length 1.5m
Status indicator Two color LED light, indicate power or communication status
Operating System Windows 98、Me、2K、XP、200, Unix and Linux
Size 140mm*83mm*60mm
Others Can provide the universal interface function library for various operating system and language developing platform
